DAI-ATLAS SWARM · CIVIL & COMMERCIAL
Mothership edge + modular nano nodes for ALPR, Amazonía thermal, disaster SAR, and LoRa mesh — JSON events only, fused in DAI-ATLAS with satellite and VTOL. No defense payloads on this channel.
Didactic guide
Understand DAI-ATLAS SWARM without being a tech expert. Step by step.
Think of many smart doorbells across the city: they do not film private life all day; they ring when something you already authorized occurs, and your team decides what to do.
A small aircraft with no pilot inside. Someone on the ground flies it, or it follows an authorized route. Many municipalities already use them to inspect works, assess fire damage, or plan the city — not to watch everyone all day.
Instead of one large drone, several small helpers spread across the area. Each covers a piece. If one loses signal, another can relay the message — like neighbors passing a note to the same meeting point.
Nano nodes cannot reach the internet all the time. A mothership solves that: a larger VTOL (CW-25E) or a fixed tower with an edge computer. It receives short messages and forwards them to the DAI-ATLAS map.
For municipalities and parking operators. A camera sees the car, finds the plate, reads letters and numbers (like scanning a document), and sends: “plate X, time Y, place Z”. It does not stream the whole street all day.
Under the forest canopy, mobile signal is often weak. Nanos can land and act as LoRa radio relays (short messages, long range, low battery). Thermal cameras see heat: a human body (~37 °C) stands out from the background — useful with environmental permits or coordinated emergencies.
Profile U3-C: the nano helps estimate where someone might be trapped after a disaster. It sends an alert to the map; an emergency responder decides next steps. Civil rescue, not military operations.
ESP32-S3 + swappable cartridges — ALPR, thermal, civil SAR SLAM, LoRa relay. INT8 pipelines on GAP8 / Orin offload.
Mission thread router, sector mapping, LoRa gateway, 4G/5G/sat uplink to Atlas.
Orchestrator + analyst fuse swarm tracks with Sentinel layers and field VTOL for civil operators.
Municipal, environmental, and emergency dashboards — audit trail and legal basis on every event.
ALPR, illegal construction, perimeter patrol — JSON events only, no video uplink.
CW-20E + Jetson Orin Nano or fixed tower edge node
Municipalities · Parking operators · Smart city integrators
Under-canopy thermal + LoRa mesh fused with satellite in DAI-ATLAS.
CW-25E VTOL mothership + LoRa gateway
Environmental agencies · Formal mining · Regional governments
| ID | Profile | Edge Pack | Atlas event |
|---|---|---|---|
| U1 | Transit & asset | pack-alpr-int8 | vehicle.plate.match |
| U3-C | Disaster SAR (civil) | pack-indoor-slam-civil-int8 | sar.victim.likelihood |
| U4 | Amazonía thermal | pack-thermal-human-int8 | thermal.human.detected |
| R3 | LoRa mesh relay | pack-lora-relay | node.relay.parked |
Tactical ISR, judicial correlation, and cooperative designation → /dai/defensa#swarm
Small drone swarms in popular fiction show lethal autonomy without accountability. DAI-ATLAS SWARM civil programs are built differently: alerts and JSON events only, mandatory legal basis, and operator acknowledgment — never lethal autonomy on this channel.
Nano nodes run INT8 Edge Packs locally. Atlas receives structured alerts — plate match, thermal signature, SAR likelihood — not continuous video uplink.
Sensitive matches require operator acknowledgment in DAI-ATLAS before escalation. No autonomous engagement from civil kits S1 or S2.
Municipal contract, environmental permit, or emergency decree — stored with the event for audit and institutional review.
Tactical ISR, judicial correlation, and designation programs run under B2G contract at /dai/defensa#swarm — blocked on public ingest.
Firmware publishes this JSON. Atlas upserts a live track and stores the event for audit. Civil profiles only on public demo; authenticated org API for institutional programs.
{
"nodeId": "nano-lim-014",
"mothershipId": "moth-cw20e-01",
"missionThreadId": "thread-miraflores-patrol-2026-05-31",
"payloadProfile": "U1_transit",
"eventType": "vehicle.plate.match",
"confidence": 0.94,
"geo": {
"lat": -12.1194,
"lng": -77.0342,
"alt_m": 42,
"accuracy_m": 3.2
},
"payload": {
"plate": "ABC-123",
"list_id": "municipal-alpr-q2",
"edge_pack": "pack-alpr-int8"
},
"legalBasis": "Municipal contract MC-2026-014",
"timestamp": "2026-05-31T18:00:00.000Z"
}Demo ingest — civil profiles only, fused as Atlas tracks (source: swarm).
…
Deploy Atlas-S1 or S2 in Peru — field quote in 48h.
Request civil swarm quote
